ODM Single Side Water Curtain Spray Booth With Two Explosion Light

Name: ODM Single Side Water Curtain Spray Booth With Two Explosion Light
Brand: Songqi
Price: 1 USD

Quality ODM Single Side Water Curtain Spray Booth With Two Explosion Light for sale

Place of Origin : Guangdong, China

Brand Name : Songqi

Model Number : SQSB100

Certification : ISO9001

Supply Ability : 30 Set/Sets per Month

Price : Negotiable

MOQ : Negotiable

Payment Terms : L/C, D/A, D/P, T/T

Delivery Time : 15-20

Packaging Details : Wooden box

Coating : Painting

Voltage : 110V/120V/127V/208V/220V /240V/380V/415V/460V

Power : 7KW

Dimension(L*W*H) : W2400*D2200*H2400mm

Weight : 200KG

lighting : two explosion light

Size : W2400*D2200*H2400mm

Exhausting system : 4KW centrifugal fan

Water pump : 3HP high quality vertical water pump and enviromental PVC tube

Style : Single side water curtain and Up exhaust

Underframe : 40mm stainless steel square

Contact Now

Single Side Water Curtain Spray Booth With Two Explosion Light

High quality stainless steel water spray booth

Product Application

Water curtain spray cabinet is mainly composed of a spray chamber, a water tank, adjustable feet cup, plate and the top plate (by bolts), positive overflow tank, water curtain plate, scroll plate, diversion plate, water retaining plate, front curtain plate, paint mist purification (water pipe), gas water separation chamber, water tank, water filter circulating system, explosion-proof lighting device, axial fan, water pump and pipe fittings (movable and detachable) and control system components, (zigzag plate, scroll device, gas separation chamber of unique structure, high efficiency of removing paint)

SPECIFICATIONS FOR UV CURING MACHINE
Size	W2400D2200H2400m


Style	Single side water curtain


Frame	Side plate: 1.2mm stainless steel plate Bottom water tank: 1.5mm stainless steel plate Water cuitain plate: 1.5mm stainless steel plate Underframe:40mm stainless steel square


Water pump	3HP high quality vertical water pump Enviromental PVC tube
Exhausting system	4KW fan
Light	2 lamp explosion-proof lamp

Main Features

1) It make a better working environment to keep workeer's health.

2) Small area, saving space

ODM Single Side Water Curtain Spray Booth With Two Explosion Light

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery oversea
